4" x 1-1/4" Nomadic Wheel Rigid Caster - 300 lbs. Capacity
4" x 1-1/4" Nomadic Wheel Rigid Caster - 300 lbs. Capacity
Product Overview
The Nomadic wheel is quiet rolling, provides a cushioned ride, and is impact-resistant, making it a great wheel for carts that carry sensitive cargo. With a flat tread, this wheel works well on hard floors, and the high-performance thermo-elastomer tread works great over bumps and thresholds.
Tread: High-Performance Thermo-Elastomer, Non-Marking, Chemically Bonded To Core This caster is listed with wheel diameter 4", tread width 1-1/4", load capacity 300 Lbs., tread type High-Performance Thermo-Elastomer, Non-Marking, Chemically Bonded To Core, and bearing type Annular Ball Bearing.
Key Features
- Load Capacity: 300 Lbs.
- Wheel Diameter: 4"
- Tread Width: 1-1/4"
- Tread: High-Performance Thermo-Elastomer, Non-Marking, Chemically Bonded To Core
- Bearing: Annular Ball Bearing
Ideal For
Choose this product if you need:
- A caster matching the listed wheel, capacity, and mounting specifications
- Loads within the listed 300 Lbs rating
- Applications matching the listed 4" x 1-1/4" wheel dimensions
- Applications needing the listed High-Performance Thermo-Elastomer, Non-Marking, Chemically Bonded To Core wheel or tread
Not Ideal For
Not ideal when the load exceeds 300 Lbs, the equipment requires a wheel other than 4" diameter by 1-1/4" tread width, or a brake or swivel lock is required but not listed.
Product Details
Review the product details below to confirm the wheel diameter, tread width, load capacity, wheel or tread material, bearing, overall height, and SKU option match the caster required for your equipment.
Shared Product Details
| Brand | Durable Superior Casters |
| Wheel Diameter | 4" |
| Tread Width | 1-1/4" |
| Wheel Color | Gray/Gray |
| Load Capacity | 300 Lbs. |
| Overall Height | 5-1/8" |
| Bearing Type | Annular Ball Bearing |
| Tread Type | High-Performance Thermo-Elastomer, Non-Marking, Chemically Bonded To Core |
| Core Type | Polyolefin Core |
| 2-3/8" x 3-5/8" Plate | Bolt Hole Pattern |
| Bolt Hole Diameter | 5/16" |
| 3-1/8" x 4-1/8" Plate | Bolt Hole Pattern |
| Durometer | Shore A 65 (+/-5) |
Available SKU Options
Compare the configuration details below and select the SKU that matches your equipment.
| SKU | Configuration Details |
| 76NM40GI4306YY | Plate Size: 2-3/8" x 3-5/8" Plate |
| 76NM40GI4311YY | Plate Size: 3-1/8" x 4-1/8" Plate |
Frequently Asked Questions
What is this product used for?
Use it when you need a caster matching the listed wheel, capacity, and mounting specifications.
What should I check before ordering?
Confirm the wheel diameter, tread width, load capacity, and bearing or bore shown in Product Details against the equipment being fitted.
What bearing does it use?
The source lists Annular Ball Bearing.
